Applications:
- ACAR conductor Used as bare overhead transmission cable and as primary and secondary distribution cable.
- A good strength-to-weight ratio makes ACAR conductor applicable where both ampacity
- and strength are prime considerations in line design.
- For equal weight ACAR conductor offers higher strength and ampacity than ACSR.
Specifications:
ACAR bare conductor meets or exceeds the following ASTM specifications:
B-230 Aluminum Wire, 1350-H19 for Electrical Purposes
B-398 Aluminum Alloy 6201-T81 for Electrical Purposes
B-524 Concentric-Lay-Stranded Aluminum Conductors, Aluminum Alloy Reinforced
| Code number | Diameter | No. of wires | Areas | Linear mass | Rated strength | D.C resistance | ||||
| Wire | Cond. | A1 | A2 | A1 | A2 | Total | ||||
| mm | mm | mm2 | mm2 | mm2 | kg/km | kN | Ohm/km | |||
| 16 | 1.76 | 5.29 | 4 | 3 | 9.78 | 7.33 | 17.1 | 46.8 | 4.07 | 1.7896 |
| 25 | 2.21 | 6.62 | 4 | 3 | 15.3 | 11.5 | 26.7 | 73.1 | 6.29 | 1.1453 |
| 40 | 2.79 | 8.37 | 4 | 3 | 24.4 | 18.3 | 42.8 | 117.0 | 9.82 | 0.7158 |
| 63 | 3.5 | 10.5 | 4 | 3 | 38.5 | 28.9 | 67.4 | 184.3 | 14.8 | 0.4545 |
| 100 | 4.41 | 13.2 | 4 | 3 | 61.1 | 45.8 | 107 | 292.5 | 23.49 | 0.2863 |
| 125 | 2.98 | 14.9 | 12 | 7 | 83.7 | 48.8 | 132 | 364.1 | 29.29 | 0.2302 |
| 160 | 3.37 | 16.8 | 12 | 7 | 107 | 62.5 | 170 | 466.0 | 36.95 | 0.1798 |
| 200 | 3.77 | 18.8 | 12 | 7 | 134 | 78.1 | 212 | 582.5 | 44.78 | 0.1439 |
| 250 | 4.21 | 21.1 | 12 | 7 | 167 | 97.6 | 265 | 728.1 | 55.98 | 0.1151 |
| 250 | 3.05 | 21.4 | 18 | 19 | 132 | 139 | 271 | 746.0 | 64.67 | 0.1154 |
| 315 | 3.34 | 23.4 | 30 | 7 | 263 | 61.4 | 325 | 894.4 | 62.4 | 0.0916 |
| 315 | 3.43 | 24 | 18 | 19 | 166 | 175 | 341 | 940.0 | 81.48 | 0.0916 |
| 400 | 3.77 | 26.4 | 30 | 7 | 334 | 78 | 412 | 1135.8 | 76.82 | 0.0721 |
| 400 | 3.86 | 27 | 18 | 19 | 211 | 222 | 433 | 1193.7 | 100.3 | 0.0721 |
| 450 | 3.99 | 28 | 30 | 7 | 376 | 87.7 | 464 | 1277.8 | 86.42 | 0.0641 |
| 450 | 4.1 | 28.7 | 18 | 19 | 237 | 250 | 487 | 1342.9 | 112.84 | 0.0641 |
| 500 | 4.21 | 29.5 | 30 | 7 | 418 | 97.5 | 515 | 1419.8 | 96.03 | 0.0577 |
| 500 | 4.32 | 30.2 | 18 | 19 | 263 | 278 | 542 | 1492.1 | 125.38 | 0.0577 |
| 560 | 4.46 | 31.2 | 30 | 7 | 468 | 109 | 577 | 1590.1 | 107.55 | 0.0515 |
| 560 | 3.45 | 31.1 | 54 | 7 | 505 | 65.5 | 570 | 1573.9 | 103.53 | 0.0516 |
| 630 | 3.72 | 33.4 | 42 | 19 | 456 | 206 | 662 | 1826.0 | 134.59 | 0.0458 |
| 630 | 3.8 | 34.2 | 24 | 37 | 272 | 420 | 692 | 1909.0 | 169.14 | 0.0458 |
| 710 | 3.95 | 35.5 | 42 | 19 | 514 | 232 | 746 | 2057.8 | 151.68 | 0.0407 |
| 710 | 4.03 | 36.3 | 24 | 37 | 307 | 473 | 780 | 2151.4 | 190.61 | 0.0407 |
| 800 | 4.19 | 37.7 | 42 | 19 | 579 | 262 | 840 | 2318.7 | 170.9 | 0.0361 |
| 800 | 4.28 | 38.5 | 24 | 37 | 346 | 533 | 879 | 2424.2 | 214.78 | 0.0361 |
| 900 | 4.44 | 40 | 42 | 19 | 651 | 294 | 945 | 2608.5 | 192.27 | 0.0321 |
| 900 | 3.66 | 40.3 | 54 | 37 | 569 | 390 | 959 | 2649.5 | 207.79 | 0.0321 |
| 1000 | 3.8 | 41.8 | 72 | 19 | 818 | 216 | 1034 | 2855.4 | 195.47 | 0.0289 |
| 1000 | 3.86 | 42.5 | 54 | 37 | 632 | 433 | 1066 | 2943.9 | 230.88 | 0.0289 |
| 1120 | 4.02 | 44.3 | 72 | 19 | 916 | 242 | 1158 | 3198.1 | 218.92 | 0.0258 |
| 1120 | 4.09 | 45 | 54 | 37 | 708 | 485 | 1194 | 3297.2 | 258.58 | 0.0258 |
| 1250 | 4.25 | 46.8 | 72 | 19 | 1022 | 270 | 1292 | 3569.3 | 244.33 | 0.0231 |
| 1250 | 4.32 | 47.5 | 54 | 37 | 791 | 542 | 1332 | 3679.9 | 288.6 | 0.0231 |
| 1400 | 4.5 | 49.5 | 72 | 19 | 1145 | 302 | 1447 | 3997.6 | 273.65 | 0.0207 |
Construction:
ACAR Conductor Aluminium alloy 1350-H19 wires, concentrically stranded about an Aluminium alloy 6201 core.
1-5KM per roll. Packed by steel drum . Other packing available according to client`s Request.
Sheath Mark:
The following printing(white hot foil indentation)is applied at 1meter intervals. a. Supplier: Guanglian or as customer required; b. Standard Code(Product Type, Fiber Type,Fiber Count); c. Year of manufacture: 7 years; d. Length marking in meters.
Port：
Shanghai/Guangzhou/Shenzhen
Lead Time:
| Quantity(KM) | 1-300 | ≥300 |
| Est.Time(Days) | 15 | To be begotiated! |
Note:
The Packing standard and details as above is estimated and final size & weight shall be confirmed before shipment.
The cables are packed in carton, coiled on Bakelite & steel drum. During transportation, right tools should be used to avoid damaging the package and to handle with ease. Cables should be protected from moisture,kept away from high temperature and fire sparks,protected from over bending and crushing,protected from mechanical stress and damage.
